Description

Overview

The Edwards C2M-PDHRC Smoke Detector is a state-of-the-art, two-wire photoelectric smoke detector designed for use in commercial and industrial fire alarm systems. It features a built-in fixed temperature and rate-of-rise heat sensor, an auxiliary relay, and self-diagnostic capabilities, ensuring reliable performance and early detection of fire hazards.

Key Features

• Photoelectric Smoke Sensing: Utilizes a photoelectric sensor to detect smoke particles, providing early warning of potential fire hazards.

• Integrated Heat Detection: Combines fixed temperature and rate-of-rise heat sensors to enhance detection capabilities.

• Auxiliary Relay: Includes an auxiliary relay for additional control options.

• Self-Diagnostics: Equipped with self-diagnostic features to monitor the detector’s performance and ensure reliability.

• Two-Wire Operation: Simplifies installation and reduces wiring complexity by operating on a two-wire system.

• Wide Operating Voltage: Compatible with 12–24 VDC power supplies, offering flexibility in various installations.

Specifications

• Model: C2M-PDHRC

• Sensor Type: Photoelectric with fixed temperature and rate-of-rise heat detection

• Relay: Auxiliary relay included

• Diagnostic: Self-diagnostic capabilities

• Wiring: Two-wire system

• Operating Voltage: 12–24 VDC

• Humidity Range: 0–95% non-condensing

• Operating Temperature: 32°F to 100°F (0°C to 38°C)

• Dimensions: 5 inches (127 mm) diameter x 2 inches (51 mm) height

Applications

The Edwards C2M-PDHRC Smoke Detector is ideal for use in a variety of commercial and industrial settings, including:

• Office buildings

• Warehouses

• Manufacturing facilities

• Educational institutions

• Healthcare facilities

Its advanced detection capabilities and reliable performance make it a suitable choice for environments where early fire detection is critical.
