Description

The Edwards WGSWA Outdoor Speaker is a weather-resistant notification appliance designed for use with compatible commercial fire alarm and emergency communication systems. Featuring a white housing with an ALERT marking, the speaker is engineered to deliver clear, intelligible voice communication while, at the same time, operating reliably in demanding indoor and outdoor environments. Additionally, its low-profile design provides a clean, professional appearance suitable for a wide range of commercial applications.

Designed as part of the Edwards Genesis WG Series, the WGSWA combines high-fidelity audio performance with field-selectable wattage settings to provide installation flexibility. Furthermore, the speaker supports both 25 VRMS and 70 VRMS audio systems through a field-selectable switch, thereby simplifying integration into compatible emergency communication systems. As a result, it is well suited for new construction, retrofit projects, and replacement applications where compatibility has been confirmed.

Product Functions

The Edwards WGSWA performs several important functions within compatible emergency communication systems, including:

• Providing high-quality audible notification through an integrated speaker
• Supporting indoor and outdoor commercial installations
• Operating with compatible 25 VRMS and 70 VRMS audio systems
• Providing field-selectable speaker wattage settings
• Supporting emergency communication and mass notification applications
• Integrating with compatible commercial fire alarm systems

Features & Benefits

Outdoor-Rated Construction

The WGSWA is engineered for outdoor and wet-location applications with a weather-resistant design. Additionally, it is suitable for challenging environments exposed to rain, snow, dust, and temperature extremes when installed with compatible mounting accessories.

High-Fidelity Audio Performance

The speaker is designed to provide clear voice reproduction with excellent speech intelligibility. Furthermore, the Genesis WG Series achieves a high Speech Transmission Index (STI), supporting effective emergency communication within compatible systems.

Dual-Voltage Audio Compatibility

The WGSWA supports both 25 VRMS and 70 VRMS audio systems through a field-selectable switch. Consequently, the speaker offers flexibility for a variety of commercial voice evacuation and emergency communication applications.

Field-Selectable Wattage Taps

The speaker features selectable output taps of 1/4, 1/2, 1, and 2 watts. Additionally, the selected setting remains visible after installation, allowing convenient inspection and maintenance.

White Housing with ALERT Marking

The appliance features a white housing with an ALERT marking, making it suitable for applications where differentiation between emergency communication and fire alarm notification is desired. Moreover, the durable housing provides a clean, professional appearance for commercial environments.

Low-Profile Commercial Design

Its compact, low-profile housing projects approximately 1.55 inches from the mounting surface, allowing the speaker to blend into a variety of architectural settings. As a result, it is suitable for both new construction and retrofit projects.

Technical Specifications

Manufacturer: Edwards

Model: WGSWA

Series: Genesis WG Series

Product Type: Outdoor Speaker

Housing Color: White

Front Marking: ALERT

Mounting Style: Wall

Application: Indoor and Outdoor Commercial Use

Speaker Voltage: 25 VRMS or 70 VRMS (Field Selectable)

Speaker Tap Settings:

• 1/4 Watt
• 1/2 Watt
• 1 Watt
• 2 Watts

Frequency Response: 400 Hz to 4,000 Hz

Operating Temperature: -40°F to 151°F (-40°C to 66°C)

Environmental Rating:

• NEMA 4X
• IP66 (Installed per manufacturer requirements)
• IP67 Device Compliance

Construction: Weather-Resistant Commercial Housing

Specifications should be verified with the manufacturer’s documentation for the intended application.

Typical Applications

The Edwards WGSWA is commonly used in compatible emergency communication and commercial fire alarm systems serving:

• Schools and universities
• Healthcare facilities
• Hotels
• Parking garages
• Industrial facilities
• Manufacturing plants
• Warehouses
• Transportation terminals
• Commercial office buildings
• Outdoor covered walkways

Application suitability should always be verified according to the system design and project requirements.

Compatibility Information

The Edwards WGSWA is designed for operation with compatible commercial fire alarm and emergency communication systems utilizing 25 VRMS or 70 VRMS speaker circuits. Additionally, the speaker is compatible with Genesis WG Series mounting accessories for indoor and outdoor installations. Before purchasing or installing the speaker, however, compatibility should always be verified with the intended audio system and mounting configuration. Furthermore, confirming compatibility helps support proper communication between system components, thereby contributing to the intended operation of the overall emergency communication system.

Why Choose the Edwards WGSWA?

The Edwards WGSWA Outdoor Speaker combines high-fidelity audio performance, dual-voltage operation, weather-resistant construction, and a low-profile commercial design in a dependable notification appliance. Additionally, its field-selectable wattage taps, white housing with ALERT marking, and compatibility with Genesis WG Series accessories provide flexibility for a wide range of commercial indoor and outdoor applications. As a result, it offers a practical solution for compatible emergency communication systems requiring a durable outdoor speaker.
