The Fire-Lite D365PL intelligent non-relay photoelectric duct smoke detector. And DNRW watertight non-relay photoelectric duct smoke detector features a pivoting housing. That fits square and rectangular footprints capable of mounting to a round or rectangular duct.
The DNRW duct smoke detector, with its NEMA-4 rating, i s listed as a watertight, UV-resistant enclosure. Protect against falling dirt, rain, windblown dust, splashing, and hose-directed water, allowing operators to use the detector in extreme environments.
These units sense smoke in the most challenging conditions. Operating in airflow speeds of 100 to 4,000 feet per minute (0.5 – 20.32 m/s). Temperatures of -4°F – 158°F (-20°C – 70°C), and a humidity range of 0 – 93 percent (non-condensing).
An improved cover design isolates the sensor head, which allows for ease of maintenance. A cover tamper feature indicates a trouble signal for a removed or improperly installed sensor cover. The housing provides a 3/4-inch conduit knockout and ample space to facilitate easy wiring and mounting of a relay module.
The Fire•Lite D365PL(A) duct smoke detectors can b e customized to meet local codes. And specifications without additional wiring and are compatible with all previous models, including remote test accessories.
-Photoelectric, integrated low-flow technology
-Air velocity rating from 100 ft/min – 4,000 ft/min (0.5 m/s – 20.32 m/s)
-Versatile mounting options: square or rectangular configuration
-Broad ranges for operating temperature (-4°F – 158°F, -20°C – 70°C) and humidity (0% – 93% non-condensing)
-Sampling tube installed from the front or back of the detector with no tools required
-Cover tamper signal
-Increased wiring space with a newly added 3/4″ conduit knockout
-Easily accessible code wheels on sensor head (Included with D365PL/D365PLA)
-Clear cover for convenient visual inspection (D365PL(A) only)
-Remote testing capability
-Requires com line power only
-Housing accommodates an addressable relay module, sold separately, (CRF-300) for applications requiring a Form-C relay
| Weight | 3 lbs |
|---|---|
| Dimensions | 16 × 7 × 7 in |
