The Fire-Lite ECC-RM is a commercial remote microphone designed for use with compatible Fire-Lite Emergency Command Center voice evacuation systems. It allows authorized personnel to broadcast live ALL CALL paging messages across connected speaker circuits from a remote location within a building.

The ECC-RM includes a built-in push-to-talk microphone housed inside a sturdy surface-mounted cabinet. A keyed lock helps restrict access to qualified personnel, while the straightforward operator interface supports fast emergency announcements in commercial fire alarm and mass notification applications.

Product Functions

• Provides remote live voice paging
• Broadcasts ALL CALL messages across speaker circuits
• Extends microphone access to remote building locations
• Supports emergency voice evacuation systems
• Provides push-to-talk microphone operation
• Restricts access through a keyed cabinet
• Communicates with the primary Emergency Command Center
• Supervises connected data and audio wiring
• Supports multiple remote microphone locations

Electrical & System Information

The ECC-RM requires an external data bus connection, an external audio riser connection, and a 24 VDC operator interface power connection supplied by the compatible Emergency Command Center main console.

The system supports Class A Style Z and Class B Style Y wiring configurations. Up to eight ECC-RM remote microphones may be connected to a compatible ECC-50 or ECC-100 primary operating console, subject to system design and installation requirements.

Features

• Commercial remote paging microphone
• Built-in push-to-talk microphone
• ALL CALL paging capability
• Secure keyed cabinet
• Optional thumb lock compatibility
• Modular system design
• Simple operator interface
• Surface-mounted enclosure
• Class A Style Z wiring support
• Class B Style Y wiring support
• Supports up to eight remote microphones
• External data bus connection
• External audio riser connection
• 24 VDC operating power
• Designed for emergency communication systems

Mounting & Design

The ECC-RM is supplied in a compact surface-mounted metal cabinet designed for installation at remote emergency communication locations. Typical mounting areas include security desks, building lobbies, fire command rooms, administrative offices, and other supervised locations where emergency paging access is required.

The enclosure includes a lockable door to help prevent unauthorized use. Internal terminal connections support the required data bus, audio riser, and operator interface power wiring from the primary Emergency Command Center.

Protection & Applications

Suitable for:

• Emergency Voice Evacuation Systems
• Commercial Fire Alarm Systems
• Mass Notification Systems
• Schools and Universities
• Hospitals
• Healthcare Facilities
• Office Buildings
• Factories
• Auditoriums
• Theaters
• Military Facilities
• Dormitories
• Restaurants
• Places of Worship

Compatibility

Compatible with:

• Fire-Lite ECC-50 Emergency Command Center
• Fire-Lite ECC-100 Emergency Command Center
• Fire-Lite ECC-50E Emergency Command Center
• Fire-Lite ECC-100E Emergency Command Center
• Compatible Emergency Command Center Speaker Circuits
• Compatible Fire-Lite Data Bus Connections
• Compatible Fire-Lite Audio Riser Connections
• Fire-Lite Emergency Voice Evacuation Systems

Always verify compatibility with the installed Fire-Lite Emergency Command Center, system firmware, wiring class, audio riser, data bus, power supply capacity, and project requirements before installation.

Technical Specifications

Manufacturer: Fire-Lite

Parent Company: Honeywell

Model: ECC-RM

Product Type: Remote Emergency Paging Microphone

Microphone Operation: Push-to-Talk

Paging Function: ALL CALL

Operating Power: 24 VDC from Primary Console

Data Connection: External Data Bus

Audio Connection: External Audio Riser

Wiring Support: Class A Style Z and Class B Style Y

Maximum Quantity: Up to Eight ECC-RM Units per Compatible Primary Console

Enclosure: Lockable Surface-Mounted Cabinet

Access Control: Keyed Lock with Optional Thumb Lock

Installation: Indoor Commercial Applications

System Type: Emergency Voice Evacuation and Mass Notification

Compliance: Installation must follow NFPA 72, applicable local codes, approved system documentation, and project requirements.

Applications

The Fire-Lite ECC-RM is designed for commercial emergency communication systems requiring live voice paging from locations away from the primary operating console. Typical applications include schools, hospitals, healthcare facilities, factories, theaters, auditoriums, military facilities, restaurants, dormitories, places of worship, office buildings, and other occupancies using compatible Fire-Lite Emergency Command Center equipment.
