Description

Gentex GES24-1575WR Evacuation Strobe Series is a low profile strobe (GES), combination horn/strobe (GEC) or horn (GEH) that offers dependable audible and visual alarms.

The GES/GEC offers fixed candela models of 15/75 and 177 candela. Listed to ANSI/UL 464 and ANSI/UL 1971, CAN/ULC listed, applicable IBC/IFC/IRC Standards and NFPA 72.

Gentex GES24-1575WR Evacuation Strobe Standard Features

• Lower installation and operating costs
• Nominal voltage 24VDC
• Features SuperSlide® bracket – ease of supervision testing
• Features Checkmate® – instant voltage verification
• Synchronize strobe and/or horn by using Gentex AVSM control module
• Prewire the entire system, install the mounting bracket, then install signals
• Input terminals 12 to 18 AWG
• Switch selection for high or low dBA
• Switch selection for chime, whoop, mechanical and 2400Hz tone
• Switch selection for continuous or temporal 3 (not available on whoop tone) audible signal
• Tamperproof re-entrant grill
• Surface mount with the GSB (Gentex Surface Box)
• Silence is audible while the visual appliance will remain flashing
• Rugged die-cast metal mounting bracket
• ALERT and AGENT text bezel available as an accessory
• Faceplate available in red or off-white

The Commander2 Series is a low profile strobe, horn and horn/strobe combination that offers dependable audible and audible/visual alarms and the absolute lowest current available.

The GE Series is available in fixed candela options of 15/75 and 177. The Commander2 Series horn offers a continuous or synchable temporal 3 in 2400Hz and mechanical and, chime as well as a whoop tone. All tones are easy for the professional to change in the field by using switches.
