The Honeywell E3ID2-C

The expandable Emergency Evacuation System by Gamewell-FCI offers several cabinet-size options. The E3 Series System is a modular design that allows a wide range of configurations to form an integrated, distributed fire alarm system. These cabinet options allow for sturdy and modern installations. The E3 Series cabinet assembly is a compact, wall-mounted enclosure. A typical cabinet includes a backbox and an outer locking door. In addition, there are several inner door options and mounting plates to accommodate a variety of E3 Series sub-assemblies. Each cabinet backbox includes mounting patterns for plates to allow the installer to arrange and secure the sub-assemblies to the backbox. The backbox knockouts are also positioned at numerous points to allow conduit access into the enclosure.

Four Annunciator cabinet sizes provide the maximum flexibility that can meet any application:

• Cabinet AA offers 2-slot or 3-slot options to accommodate any of the following configurations:
  – Inner door, 2 slots allows space for one LCD-E3 or LCD-SLP and one ASM-16
  – Inner door, 3 slots allows space for any combination of three modules: ASM16, NGA, or an ANU-48
• Cabinet A1 houses one NGA or one ASM-16/ANU-48.
• Cabinet A2 accommodates a single LCD-E3.
• E3BB-FLUSH-LCD or E3BB-NGA-FLUSH. The E3BB-R-B-Slim or B-Slim contains the 600 Series cabinet. Cabinet B includes a mounting plate that contains a space for the following modules:
• ILI-MB-E3/ILI95-MB-E3
• PM-9/PM-9G sub-assemblies
• Batteries set inside the backbox Additional sub-assembly options mounted on the backbox include the DACT-E3 and RPTE3. The 2 slots inner door houses the following options:
• One LCD-E3 module and
• Either one ASM-16/ANU-48 or one NGA module

The Honeywell E3ID2-C
