Description

The Silent Knight IDP-CONTROL is an addressable notification module for use with Silent Knight IFP-series fire alarm control panels (FACPs). Also, the IDP-Control gives you the flexibility to

Honeywell IDP-CONTROL

The IDP-Control i s an addressable notification module for Honeywell Farenhyt Series fire alarm control panels (FACPs). The IDPControl gives you, the flexibility to add notification circuits. They a re needed on an Farenhyt FACP signaling line circuit (SLC) loop.
Provides supervised monitoring of wiring to load devices. That requires an external power supply, like bells, horns, and strobes. It i s capable of Class B and Class A supervision.
Upon command from the FACP, the IDP-Control will disconnect the supervision. And connect the external power supply across the load device.
The disconnection of the supervision provides a positive indication to the panel that the control relay i s turned on. The external power supply i s always relayed isolated from the SLC loop. That a trouble condition on the power supply will never interfere with the rest of the system.
Installation
The IDP-Control mounts directly into a 4” square electrical box. The box must have a minimum depth of 2-1/8”. A surface-mount electrical box (System Sensor® PN SMB500) i s available from Honeywell.

Compatibility
The IDP-Control i s compatible with the following Farenhyt Series FACPs:
IFP-2100 / IFP-2100ECS / RFP-2100
IFP-2000 / IFP-2000ECS / RPS-2000
IFP-1000 / IFP-1000ECS
IFP-300 / IFP-300ECS
IFP-100 / IFP-100ECS
IFP-75
IFP-50
