Description

In the first place, the model Notifier FST-851RA Heat Detector is an intelligent sensor that utilizes a state-of-the-art thermistor sensing circuit for a fast response. As well, these sensors are designed to provide open area protection with a 50-foot spacing capability as approved by UL 521. Besides, Notifier FST-851RA Heat Detector is a rate-of-rise temperature sensor with a 135° F fixes temperature alarm. Two LEDs on each sensor light to provide a local, visible sensor indication. Remote LED annunciator capability is available as an optional accessory. Also, is a plug-in thermal detector with integral communication has features that surpass conventional detectors. In addition, It has a point ID capability that allows each detector address to be set with rotary, decimal address switches, providing exact detector locations. It provides effective, intelligent property protection in a variety of applications.

Specifically, require compatible addressable communications to function properly. Additionally, connect these sensors to listed-compatible control panels only. Before testing, notify the proper authorities that the system is undergoing maintenance, and will temporarily be out of service.  All sensors must be test after installation and periodically thereafter. Before cleaning notify the proper authorities that the system is undergoing maintenance, and therefore the system will temporarily be out of service. Disable the loop or system undergoing maintenance to prevent unwanted alarms.

Features / Specifications

  • Diameter: 6.1˝ (155 mm) installed in B210LP; 4.1˝ (104 mm) installed in B501
  • Height: 2.0˝ (51 mm)
  • Weight: 4.8 ounces (137 gm)
  • Installation Temperature: –4°F to 100°F (–20°C to 38°C)
  • Operating Humidity Range: 10% to 93% Relative Humidity, Non-condensing
  • Voltage Range: 15 to 32 Volts DC Peak
  • Standby Current: 300 µA @ 24 VDC (one communication every 5 seconds with LED blink enabled)
  • LED Current: 6.5 mA @ 24 VDC
  • Fixed Temperature Rating: 135°F (57°C), FST-851 and FST-851R
  • ULC Listed





Additional information

Weight 1 lbs
Dimensions 5 × 5 × 5 in
