Description

Secutron MRI-100S

Secutron’s MRI-100 Series Intelligent Addressable
Modules are designed to meet a wide range of
applications. The monitor and control modules can be
used to supervise and activate sounders, strobes, door
closers, pull stations, waterflow switches, conventional
smoke detectors and more. An eight position dip switch
allows for the address setting of the device and the
wiring class/style of the devices that are connected to
the module. All modules mount in a standard 4” x 4”
x 2 1/8” junction box

The Intelligent Addressable Priority Monitor Module
(MRI-100P) provides an address for a group of UL
Listed normally open (N.O.) initiating devices, such as
heat detectors, beam smoke detectors, 4-wire smoke
detectors, waterflow switches, manual pull stations, etc.
wired in a Class A (Style D) or Class B (Style B) initiating
circuit. The MRI-100P is equipped with a priority interrupt
to provide a fast response to emergency conditions. The
MRI-100P has an activated red LED.

The Intelligent Addressable Priority Mini Monitor Module
provides an address for a group of UL Listed Normally
Open (N.O.) initiating devices, such as heat detectors,
projected beam smoke detectors, 4-wire smoke detectors,
waterflow switches, manual pull stations, etc. wired in a
Class A (Style D) or Class B (Style B) initiating circuit.
The MRI-101P is equipped with a priority interrupt to
provide a fast response to emergency conditions. The
MRI-101P has an activated red LED.

The Intelligent Addressable Relay Module connects to
the same loop as the initiating devices and provides
two isolated sets of Form-C contacts to control a
variety of normally open or normally closed contact
applications cuch as fan operation and door closures.
The MRI-100R has an activated red LED which follows
the state of the relay contacts.
