Description

The Simplex 4090-9106 is a Class A Zone Adapter Module designed to provide an addressable interface between a conventional initiating device circuit and a Simplex IDNet or MAPNET II fire alarm system. It allows compatible conventional two wire initiating devices to be monitored as a single addressable point while maintaining Class A circuit operation.

The module features sealed electronics, onboard communication, LED status indication, and screw terminal wiring for dependable operation in commercial fire alarm systems. Its compact design fits within a standard electrical box, making installation and servicing straightforward.

Product Functions

• Monitors one Class A initiating device circuit
• Interfaces conventional initiating devices to the fire alarm control panel
• Provides one addressable monitoring point
• Reports normal, alarm, and open circuit conditions
• Continuously supervises field wiring
• Provides LED communication indication
• Supports two wire conventional initiating devices
• Communicates over the IDNet or MAPNET II signaling circuit

Electrical & System Information

The 4090-9106 communicates over the IDNet or MAPNET II signaling circuit and occupies one address on the communication loop. It supervises a Class A conventional initiating device circuit and reports its status to the fire alarm control panel.

The module includes screw terminal connections for field wiring and a visible LED that flashes during normal communication with the control panel. Device addressing is configured using an eight position DIP switch located beneath the resealable label.

Features

• Class A Zone Adapter Module
• IDNet communication
• MAPNET II communication
• One addressable monitoring point
• Class A initiating device circuit supervision
• LED communication indicator
• Eight position DIP switch addressing
• Screw terminal wiring
• Compact enclosed design
• Dust resistant construction
• Standard four inch square box installation
• Commercial fire alarm application

Mounting & Design

The 4090-9106 is designed for installation inside a standard four inch square electrical box with an optional trim plate or cover. Its enclosed construction helps reduce dust infiltration while protecting internal electronics.

Optional semi flush and surface covers are available with a light pipe that allows the communication LED to remain visible after installation.

Protection & Applications

Suitable for:

• Commercial Fire Alarm Systems
• Conventional Initiating Device Circuits
• Office Buildings
• Hospitals
• Healthcare Facilities
• Schools and Universities
• Government Buildings
• Industrial Facilities
• Warehouses
• High Rise Buildings
• Institutional Buildings
• Manufacturing Facilities

Technical Specifications

Manufacturer: Simplex

Parent Company: Johnson Controls

Model: 4090-9106

Product Type: Class A Zone Adapter Module

Circuit Type: Class A Initiating Device Circuit

Communication: IDNet or MAPNET II

Addressing: Eight Position DIP Switch

Device Capacity: One Addressable Point

Status Indicator: Flashing LED Communication Indicator

Operating Voltage: 18 to 32 VDC Nominal

Maximum IDC Devices: Up to 20 Compatible Two Wire Initiating Devices

Mounting: Standard Four Inch Square Electrical Box

Wiring: Screw Terminal Connections

Operating Temperature: 32 Degrees Fahrenheit to 120 Degrees Fahrenheit

Relative Humidity: Up to 93 Percent Non Condensing

Application: Indoor Commercial Fire Alarm Systems

Listings: UL Listed, ULC Listed, FM Approved, and CSFM Listed. Verify product labeling, installation instructions, local codes, and project requirements before installation.

Applications

The Simplex 4090-9106 is designed for commercial fire alarm systems requiring the integration of conventional Class A initiating device circuits into an addressable fire alarm network. Typical applications include office buildings, hospitals, educational facilities, industrial plants, warehouses, government buildings, manufacturing facilities, and other commercial occupancies where conventional initiating devices must be monitored through an addressable system.
