Description

Firstly, the Simplex 4905-9914 Synchronized Flash Module (class B, style Y) is epoxy encapsulated with 18 AWG (0.82 mm2 ) wire leads; rated for 2 A NAC; requires 5 mA for power. Also, provides synchronization for Visual Notification Appliances (Strobes). Besides, Simplex 4905-9914 adds the required control to activate Simplex synchronized strobes for NACs that do not provide that control. Conventional horns or other compatible 24 VDC notification appliances on the same circuit ignore strobe synchronization and operate when the NAC is in alarm.

Simplex 4905-9914 Synchronized Flash Module provides a 2-wire synchronized strobe output that also operates compatible 24 VDC conventional reverse polarity notification appliances.

Features / Specifications

• Encapsulated package with color coded wire leads provides 1 Hz strobe synchronization as well as maintains supervision continuity
• Conventional horns and other DC appliances operate on the same 2-wire circuit
• Models are available with Class B or Class A output
• Small size allows convenient mounting
• Input Voltage Range: 16 VDC to 33 VDC
• Temperature Range: 32° to 122° F (0° to 50° C)
• Humidity Range: 10% to 93%, non-condensing at 100° F (38° C)
• Mount: Control panel or separate 4” (51 mm) square electrical box, 1-1/2” (38 mm) minimum depth
