Description

Firstly, the Simplex 4905-9922 is a Class A Synchronized Flash Module. Also, the Simplex 4905-9922  Synchronized Flash Modules provide a 2-wire synchronized strobe output that also operates compatible 24 VDC conventional reverse polarity notification appliances.

In general, model Simplex 4905-9922 adds the required control to activate Simplex synchronized strobes for NACs that do not provide that control. Conventional horns or other compatible 24 VDC notification appliances on the same circuit ignore strobe synchronization and operate when the NAC is in alarm.

Features / Specifications

• Encapsulated package with color-coded wire leads provides 1 Hz strobe synchronization as well as maintains supervision continuity
• Conventional horns together with other DC appliances operate on the same 2-wire circuit
• Models are available with Class B or Class A output
• Small size allows convenient mounting
• Dimensions: 1-3/8” x 2-7/16” x 13/16” D (35 mm x 62 mm x 20 mm)
• Epoxy-encapsulated: 8” (203 mm) in/out 18 AWG (0.82 mm2) wire 4905-9922 Class A Synchronized Flash Module leads
• Requires 5 mA for power
• Rated for 2 A NAC
• Input Voltage Range: 16 VDC to 33 VDC
• Output Ratings: Up to 35 maximum strobes per synchronized circuit
• Mounting: Mount in the control panel or separate 4” (51 mm) square electrical box, 1-1/2” (38 mm) minimum depth
