Description

The System Sensor P2RLED is a wall mounted LED two wire horn strobe designed to provide dependable audible and visual notification for commercial fire alarm systems. It combines a high output electronic horn with an energy efficient LED strobe, delivering synchronized emergency notification while reducing current consumption compared to traditional xenon notification appliances.

Part of the System Sensor L Series LED notification appliance family, the P2RLED features a low profile design, selectable candela settings, and simplified installation using a universal mounting plate. It is engineered for commercial life safety systems requiring reliable wall mounted notification in new construction and retrofit applications.

Product Functions

• Provides audible fire alarm notification
• Provides visual emergency notification
• Supports synchronized horn operation
• Supports synchronized LED strobe operation
• Operates on two wire notification appliance circuits
• Supports selectable candela output
• Produces Temporal Code 3 or continuous horn signaling
• Supports commercial fire alarm systems

Electrical & System Information

The P2RLED operates from regulated 24 VDC notification appliance circuits and utilizes LED strobe technology for significantly reduced current consumption. The integrated strobe provides field selectable candela settings of 15, 30, 75, 95, 110, 135, 177, or 185 candela, depending on the selected configuration. The appliance supports synchronization with compatible fire alarm control equipment and synchronization modules.

The electronic horn provides multiple selectable sound patterns including Temporal Code 3 and continuous operation, with high and low output settings available to suit varying ambient noise conditions.

Features

The P2RLED features LED strobe technology, two wire operation, wall mounted installation, synchronized audible and visual notification, selectable candela output, low current consumption, red housing with FIRE marking, low profile construction, universal mounting plate, multiple horn tone selections, onboard shorting spring for wiring continuity testing, and dependable performance for commercial fire alarm systems.

Protection & Applications

Suitable for:

• Commercial Fire Alarm Systems
• Office Buildings
• Hospitals
• Healthcare Facilities
• Schools and Universities
• Hotels
• Government Buildings
• Industrial Facilities
• Warehouses
• Retail Buildings
• Institutional Facilities
• Indoor Wall Notification Systems

P2RLED Datasheet
