Description

The System Sensor P2WLED is a commercial wall-mount LED horn strobe designed for compatible fire alarm notification systems. As part of the L-Series with LED product family, it combines high-output audible and visual notification with energy-efficient LED technology that significantly reduces current draw compared to traditional xenon horn strobes.

The appliance features a white housing with FIRE marking, field-selectable candela settings, selectable horn output, and a plug-in design that simplifies installation and maintenance. This product is intended exclusively for commercial fire alarm installations.

Product Functions

• Provides audible emergency notification
• Provides visual emergency notification
• LED strobe signaling
• Wall-mounted installation
• Field-selectable candela output
• Selectable horn volume and tone
• Compatible with synchronized NAC circuits
• Continuous notification appliance circuit supervision

Electrical & System Information

The P2WLED operates from a regulated 24 VDC Notification Appliance Circuit (NAC) and incorporates advanced LED technology to deliver reliable visual notification while reducing current consumption and power supply requirements.

The appliance features a universal mounting plate with an onboard shorting spring for wiring continuity testing, front-access candela selection, voltage test points, and compatibility with System Sensor synchronization protocols when used with compatible fire alarm control panels or synchronization modules.

Features

• Commercial LED horn strobe
• White housing
• FIRE marking
• Low-profile wall design
• Energy-efficient LED technology
• Field-selectable candela settings
• Selectable horn output
• Plug-in construction
• Universal mounting plate
• Built-in shorting spring
• Voltage test points
• Low current draw
• Modern L-Series styling

Mounting & Design

The P2WLED installs on compatible single-gang, double-gang, 4-inch square, or surface-mount back boxes using the System Sensor universal mounting plate. Its plug-in construction minimizes wiring complexity and helps reduce installation time while allowing wiring continuity testing before the appliance is installed.

The low-profile housing provides a clean appearance and easy access for candela selection, inspection, testing, and maintenance.

Protection & Applications

Suitable for:

• Office Buildings
• Schools
• Hospitals
• Hotels
• Retail Facilities
• Warehouses
• Healthcare Facilities
• Government Buildings
• Commercial Properties

Compatibility

Compatible with:

• System Sensor L-Series Notification Appliance Circuits
• Compatible Fire Alarm Control Panels
• Regulated 24 VDC Notification Appliance Circuits
• System Sensor Synchronization Protocol
• System Sensor Surface Mount Back Boxes
• Standard Electrical Back Boxes

Always verify compatibility with the installed fire alarm control panel, notification appliance circuit, synchronization method, and project requirements before installation.

Technical Specifications

Manufacturer: System Sensor

Parent Company: Honeywell

Model: P2WLED

Series: L-Series with LED

Product Type: LED Horn Strobe

Notification Type: Audible and Visual

Mounting: Wall

Housing Color: White

Marking: FIRE

Operating Voltage: Regulated 24 VDC

Light Source: LED

Selectable Candela Settings: 15, 30, 75, 95, 115, 150, and 177 cd

Horn Settings: Selectable High/Low Volume and Temporal/Continuous Tone (panel dependent)

Synchronization: Compatible with System Sensor Synchronization Protocol

Operating Temperature: 32°F to 120°F (0°C to 49°C)

Operating Humidity: Up to 93% RH Non-Condensing

Construction: Low-Profile Indoor Design

Application: Indoor Commercial Fire Alarm Notification Systems

Listings: UL 1971, UL 464 (as applicable), ULC Listed, FM Approved, and CSFM Listed (application dependent). Verify product labeling and local code requirements before installation.

Applications

The System Sensor P2WLED is designed for commercial fire alarm systems requiring dependable audible and visual notification in indoor environments. Typical applications include office buildings, schools, hospitals, hotels, retail facilities, warehouses, healthcare facilities, government buildings, and other commercial occupancies utilizing compatible fire alarm control panels and notification appliance circuits.
