System Sensor RTS2-AOS: Remote Testing for Duct Detectors

The System Sensor RTS2-AOS is an automatic fire detector accessory designed to remotely test duct detectors. This multi-signaling accessory works with InnovairFlex 4-wire conventional duct smoke detectors. It includes a key switch to select one of two connected sensors, enabling you to test, reset, or perform both functions with a push-button switch. Additionally, you can measure sensitivity using the SENS-RDR sensitivity reader (sold separately).

Indicator LEDs for Easy Monitoring

The RTS2-AOS provides clear status indicators to ensure your duct detectors are functioning properly:

• Standby (Green Blink): The green LED blinks every 5 seconds when the duct smoke detector receives power.
• Trouble (Amber): The amber LED lights up when the sensor is missing or if the detector cover is removed. The delay in indicating trouble depends on the dip switch setting on the power board of the duct smoke detector.
• Maintenance (Amber Blink): An amber blink every 5 seconds indicates that the sensor requires cleaning or replacement.
• Alarm (Red): The red LED signals an active alarm condition.

Key Features

• LED Indicators: Standby (Green Blink), Trouble (Amber), Maintenance (Amber Blink), and Alarm (Red) LEDs to indicate detector status.
• Key Switch: Use the key switch to select the desired sensor and enable testing or resetting.
• Test/Reset Button: This feature allows you to test and reset the system easily.
• Selectable Tone: Choose between continuous or temporal tone.
• Mounting Options: Supports mounting on single or double-gang boxes.
• Compatibility: Works with InnovairFlex 4-wire conventional duct smoke detectors.
• Dimensions: 4.8″W x 5.3″H x 1.6″D (12.2 cm W x 11.9 cm H x 3.8 cm D)
• Weight: 0.35 lb. (160 g)
• Temperature Range: 14°F to 140°F (-10°C to 60°C)
• Humidity Range: 95% relative humidity, non-condensing
• Operating Voltage: 20-29 VDC
• Connections: Strip terminal, 14 AWG to 22 AWG wire
• Wiring Distance: Up to 1000 feet from the duct smoke detector
• Sounder: 85 dBA at ten feet
