Description

System Sensor SPSCWLED-SP — L-Series Indoor Ceiling Speaker-Strobe with “FUEGO” Marking

The System Sensor SPSCWLED-SP is a ceiling-mounted LED speaker-strobe from System Sensor’s modern L-Series family. It integrates a voice/tone speaker and a low-current LED strobe in a single scalable notification appliance suitable for fire alarm and emergency communication systems. The “SP” model features a “FUEGO” legend on the housing to indicate Spanish language visual notification, while its sleek design blends seamlessly into commercial interiors.

Key Features & Benefits

• Combined Audible & Visual Notification: Delivers both a high-fidelity speaker for voice or tone output and a bright LED strobe for visual alerts in one ceiling-mount device — reducing the need for separate appliances.

• LED Strobe Technology: Uses efficient LEDs that significantly lower current draw compared with legacy xenon strobes, enabling more devices per notification appliance circuit (NAC) and reducing power supply requirements.

• Field-Selectable Settings: Multiple candela options (typically 15, 30, 75, 95, 115, 150, 177 cd) allow compliance with coverage requirements without replacing hardware.

• Rotary Speaker Configuration: Supports selection of speaker voltage (25 Vrms or 70.7 Vrms) and power tap settings for flexible audio performance in various environments.

• Universal Mounting Plate: Plug-in mounting plate with onboard shorting spring simplifies wiring and allows quick continuity checks before device installation.

• DVM Test Points: Built-in digital voltage meter (DVM) points enable NAC voltage verification without removing the appliance from its mounting.

• Retrofit Friendly: Electrically compatible with legacy System Sensor SpectrAlert and SpectrAlert Advance devices, easing upgrades and also replacements.

• Economical & Modern Aesthetic: White housing and low-profile ceiling form factor fit most commercial interiors and architectural designs.
