The System Sensor SSM24-10 is a 10-inch fire alarm bell. The model has an operating temperature of -31°F to 140°F and a sound output of 86 dBA.
System Sensor SSM24-10 Model shall be an SSM or SSV Series alarm bell. Bells shall have underdone strikers and operating mechanisms. Gongs on said bells shall be no smaller than nominal 6˝/8˝/10˝ (specify size) with an operating voltage of 24VDC or 120VAC (specify by part number).
Bells shall be suitable for surface or semi-flush mounting. Outdoor surface mounted installations shall be weatherproof (using an optional WBB weatherproof electrical box). Otherwise, bells shall mount to a standard 4˝ square electrical box having a maximum projection of 2½˝. Bells shall be located as shown on the drawings or as determined by the Authority Having Jurisdiction. Bells shall be listed for indoor/outdoor use by Underwriters Laboratories and the California State Fire Marshal and approved by Factory Mutual and MEA.
For indoor use, the SSM and SSV series mount to a standard four-inch square electrical box. For outdoor applications, weatherproof backbox, model number WBB, is use.
Features / specifications
| Weight | 3 lbs |
|---|---|
| Dimensions | 7 × 7 × 6 in |
Your Payment information is processed securely. We do not store credit card details, nor have access to your credit card information.
Orders ship same day
Thousands of parts in stock
Reliable products & service
Order anytime, anywhere
The System Sensor SSM24-10 is a 10-inch fire alarm bell. The model has an operating temperature of -31°F to 140°F and a sound output of 86 dBA.
System Sensor SSM24-10 Model shall be an SSM or SSV Series alarm bell. Bells shall have underdone strikers and operating mechanisms. Gongs on said bells shall be no smaller than nominal 6˝/8˝/10˝ (specify size) with an operating voltage of 24VDC or 120VAC (specify by part number).
Bells shall be suitable for surface or semi-flush mounting. Outdoor surface mounted installations shall be weatherproof (using an optional WBB weatherproof electrical box). Otherwise, bells shall mount to a standard 4˝ square electrical box having a maximum projection of 2½˝. Bells shall be located as shown on the drawings or as determined by the Authority Having Jurisdiction. Bells shall be listed for indoor/outdoor use by Underwriters Laboratories and the California State Fire Marshal and approved by Factory Mutual and MEA.
For indoor use, the SSM and SSV series mount to a standard four-inch square electrical box. For outdoor applications, weatherproof backbox, model number WBB, is use.
Features / specifications
| Weight | 3 lbs |
|---|---|
| Dimensions | 7 × 7 × 6 in |
