Edwards FX-ISO Analog SLC Fault Isolator Module

Analog SLC Fault Isolator Module protects a Class A SLC from total collapse due to wire-to-wire short circuits. The module monitors line voltages and opens the SLC when a short is detected. The device address is set using the two rotary switches located on the front of the module. One device address i s required.

Class A-B Two-Wire Module: Acts as an interface between conventional two-wire smoke detectors and the FireworX control panel

Class A Single-Input Module. Used to connect a normally open, alarm, supervisory, or monitor type dry contact. Initiating the device circuit to the FireworX control panel

Dual Input Module. Connects two normally open, alarm, supervisory, or monitor type dry contact; initiating device circuits to the FireworX control panel

Dual Input Waterflow, Supervisory Module: Used to connect a normally open water flow alarm. And supervisory initiating device circuits to the FireworX control panel. For Class B circuit operation

SLC Fault Isolator Module: Protects a Class A SLC from total collapse due to wire-to-wire short circuits

NAC Module: Connects a supervised output circuit to a signal riser

Contact Relay Module: Provides one Form C dry relay contact and is configured to provide polarity reversal of its output

Single Input Mini Module: Connects a normally open, alarm, supervisory, or monitor-type dry contact. Initiating the device circuit (IDC) to the FireworX control panel. For Class B circuit operation
