Description

Edwards MFC-A E-FSC fire alarm family consists of 3, 5 and also 10 zone conventional fire alarm control panels, an integrated DACT/Dialer, serial annunciator modules, and serial remote relay modules. All of these components are also microprocessor-controlled. The E-FSC family is suitable for both new and retrofit installations.

E-FSC Series Panels incorporate features designed to simplify installation, operation and also maintenance. These include front panel programming, one person walk testing, and selectable IDC and NAC types. compatible smoke detectors, E-FSC provides analog type features such as remote maintenance alert and automatic drift compensation that reduces false alarms and simplifies maintenance calls.

E-FSC502 as well as E-FSC1004 panels support Class A operation by combining pairs of on-board initiating circuits (IDCs) or notification circuits (NACs) to provide the necessary Class A circuits.

FEATURES & SPECS

• IDC or NAC pairs convertible to single Class A circuits (10 and 5 IDC panels only)
• Combination Waterflow and Supervisory IDCs reduces wire and zone counts
• Front panel programmable
• Optional fully integrated DACT/Dialer for remote PC programming
• On-board relays for Alarm, Supervisory, and Trouble
• Optional serial bus relay modules are programmable for common or zone activation
• Optional serial bus remote annunciator family
• Expandable power supply on 10 IDC panel
• Trim ring available for semi-flush mounting
• Supports 2M, “SC”, 2400, 500, and 700 series detectors
• Operating temperature range
