Description

The Genesis EST G1F-VM Strobe is a visible fire alarm notification appliance designed for indoor walls. In Addition, The strobe includes a field configurable switch for selecting the desired candela output and a field configurable jumper for the strobe signal output. Also, the candela output setting comes locked in place and remains visible after final installation.

In fact, this Genesis Est G1F-VM strobe features an enhanced synchronization circuit to comply with the latest requirements of UL 1971 Signaling Devices for the Hearing Impaired and the latest Canadian standard CAN/ULC S526-02. Besides, synchronized operation requires a separately installed synchronization control module.

Furthermore, install this device in accordance with applicable requirements in the latest editions of the NFPA codes and standards and Canadian Electrical Code, Part 1, Section 32, CAN/ULC S524- 01, Standard for the Installation of Fire Alarm Systems, and in accordance with the local authorities having jurisdiction.

Features / Specifications

• Operating voltage: 24 Vdc or 24 Vfwr, nominal
• Light output: Selectable at 15, 30, 75, and 110 cd
• Wire size: 12 to 18 AWG (2.50 to 0.75 sq mm)
• Temperature: 32 to 120 °F (0 to 49 °C)
• Humidity: 0 to 93% RH, noncondensing at 90 °F (32 °C)
• UL ratings: Regulated 24 DC, Regulated 24 FWR
• ULC ratings: 20 to 31 Vdc or 20 to 31 Vfwr
