Description

Honeywell INCC-MIC Paging Microphone

The Honeywell INCC-MIC Paging Microphone Module is a microphone interface
used for emergency microphone paging. It component of the following Systems:
• E3 Series® Combined Fire and Mass Notification System
• E3 Series Broadband Voice Evacuation System
The INCC-MIC microphone provides a cost-effective microphone interface module
that can be used for paging. When it installed with the ASM-16 Addressable Switch
Module, it provides easy paging to the selected speaker zones with visual indications
of paging and zone status.

SYSTEMS
INCC-MIC: Paging Microphone Module
Microphone Box: Durable gauge steel construction with
microphone holder
Dimensions: 5.5” W x 6.5” H x 2.75” D
(14 W x 16.5 H x 7 D cm)
TEMPERATURE AND HUMIDITY RANGES
This system meets NFPA requirements for operation at 0
– 49°C/32 – 120°F and at a relative humidity 93% ± 2%
RH (non-condensing) at 32°C ± 2°C (90°F ± 3°F).
The useful life of the system’s standby batteries,
and the electronic components may be adversely affected
by extreme temperature ranges and humidity. It
recommended that this system and its peripherals be
installed in an environment with a normal room
temperature of 15 – 27°C/60 – 80°F.
STANDARDS
The INCC-MIC is designed to comply with the following
standards:
UL Standards: 864 9th Edition
2572 for Mass Notification
