MG Electronics MGT1640 Transformer

Highly reliable plug-in Class II linear power supply providing 16.5VAC output at 40VA. Built with a heavy-duty case that includes a mounting tab and screw. An auto-resetting PTC fuse provides overload protection. An LED indicates AC power input. The plug includes a ground prong and there are three screw terminals for the output, including ground.

FEATURES & SPECIFICATIONS

• Input voltage: 120VAC 60Hz
• Rate current: 2400mA
• Output voltage: AC 16.5 V +/- 5%
• No load voltage: AC 19.5VMax
• Exciting current (Io): 130mA Max. at input 120VAC
  60Hz without secondary load.
• Insulation test: 500 VDC 100MΩ Min. between input
  plug and output terminal and case.
• AC blade pull test: Pull AC blades by 35lb for one
  minute without pull out from the case.
• Temperature rise: Input120VAC 60Hz with secondary
  load 2400 mA, shall not exceed 40deg on case surface
  (By them10meter) 72deg for primary winding (By
  resistance method). At ambient temp. 25°C
• Normal operating temperature at: -10°C ~ +40°C
• Storage temperature at: -20°C ~ +70°C
• Normal operating humidity at: 30% —– 85% R.H.
