Description

The Notifier FRM-1 is a commercial addressable relay module designed for compatible Notifier intelligent fire alarm control panels. It provides two isolated Form-C dry contacts (DPDT) for controlling auxiliary equipment such as HVAC systems, door holders, smoke dampers, elevators, fans, and other building control devices.

Powered directly from the Signaling Line Circuit (SLC), the FRM-1 features FlashScan® and CLIP® communication compatibility, rotary decimal addressing, and an integral status LED for dependable operation and simplified installation. This product is intended exclusively for commercial fire alarm installations.

Product Functions

• Controls auxiliary building equipment
• Provides two isolated Form-C dry contacts
• Supports HVAC shutdown
• Controls smoke dampers
• Controls door holders
• Supports elevator interface functions
• Resets compatible four-wire smoke detector power
• Provides continuous SLC communication and supervision
• Individual address identification

Electrical & System Information

The FRM-1 operates directly from a compatible 15–32 VDC Signaling Line Circuit (SLC) and requires no separate operating power for module electronics or relay operation. The module occupies a single SLC address while both Form-C relay outputs operate simultaneously as a DPDT relay.

Two rotary decimal switches provide local addressing, while the integral LED flashes green during normal polling and illuminates steadily when the relay is activated. Circuit connections to the relay contacts are not supervised by the module.

Features

• Commercial addressable relay module
• Two isolated Form-C dry contacts
• DPDT relay operation
• FlashScan® and CLIP® compatible
• Powered directly from the SLC
• Rotary decimal addressing
• Integral green/red status LED
• Automatic device identification
• High EMI/RFI immunity
• SEMS screw terminals
• Low standby current
• Compact mounting design

Mounting & Design

The FRM-1 mounts directly to a standard 4-inch square electrical box with a minimum depth of 2⅛ inches (54 mm). An optional SMB500 surface-mount back box is available for surface installations.

Its off-white heat-resistant enclosure includes front-access rotary address switches and SEMS screw terminals that simplify installation, programming, and servicing. The module may also be installed in compatible DNR(DNRW) duct detector housings where supported.

Protection & Applications

Suitable for:

• HVAC Shutdown
• Door Holder Release
• Smoke Dampers
• Exhaust Fans
• Elevator Interface
• Building Automation Equipment
• Four-Wire Detector Power Reset
• Commercial Fire Alarm Systems

Compatibility

Compatible with:

• Notifier ONYX® Fire Alarm Control Panels
• FlashScan® Signaling Line Circuits
• CLIP® Signaling Line Circuits
• NFS2-640 Fire Alarm Control Panel
• NFS2-3030 Fire Alarm Control Panel
• AFP Series Fire Alarm Control Panels
• SMB500 Surface-Mount Back Box
• Compatible Auxiliary Equipment with Dry-Contact Inputs

Always verify compatibility with the installed fire alarm control panel, SLC protocol, firmware version, controlled equipment, and project requirements before installation.

Technical Specifications

Manufacturer: Notifier

Parent Company: Honeywell

Model: FRM-1

Product Type: Addressable Relay Module

Relay Configuration: Two Isolated Form-C Dry Contacts (DPDT)

Communication Protocol: FlashScan® and CLIP®

Operating Voltage: 15–32 VDC

Power Source: Signaling Line Circuit (SLC)

Average Operating Current: 350 µA (Direct Poll)

Average Operating Current: 375 µA (Group Poll with LED Flashing)

Maximum Current Draw: 6.5 mA (LED On)

Addressing: Rotary Decimal Switches

Address Range: 01–159 (FlashScan®), 01–99 (CLIP®)

Status Indicator: Green/Red LED

Mounting: Standard 4-Inch Square Electrical Box

Application: Indoor Commercial Fire Alarm Systems

Listings: UL Listed, ULC Listed, FM Approved, CSFM Listed, and MEA Approved (application dependent). Verify product labeling and project requirements before installation.

Applications

The Notifier FRM-1 is designed for commercial fire alarm systems requiring programmable relay control of auxiliary building equipment. Typical applications include HVAC shutdown, smoke control systems, elevator interface, door holder release, fan control, four-wire smoke detector reset, and other programmable relay functions in offices, schools, hospitals, warehouses, industrial facilities, and other commercial occupancies.
