Description

The Notifier NBG-12LX is an addressable dual-action pull station designed for compatible Notifier intelligent fire alarm control panels. The station requires two motions—push in and pull down—to initiate an alarm, helping reduce accidental activation while providing reliable manual fire alarm initiation.

The integrated addressable interface allows the fire alarm control panel to identify the exact device location during an alarm. The station features rotary address switches, a dual-color status LED, key-reset operation, and a durable polycarbonate housing for long-term commercial use. This product is intended exclusively for commercial fire alarm installations.

Product Functions

• Manual fire alarm activation
• Dual-action push/pull operation
• Individual address identification
• Alarm reporting through the SLC loop
• Continuous communication with the control panel
• Dual-color LED status indication
• Key-reset operation
• Supervised addressable device operation

Electrical & System Information

The NBG-12LX operates on compatible Notifier Signaling Line Circuits (SLC) with a 24 VDC nominal operating voltage and automatically communicates using either FlashScan® or CLIP protocol, depending on the connected control panel.

Two rotary decimal switches provide address settings from 01–159 on FlashScan systems and 01–99 on CLIP systems. The station is supervised continuously by the fire alarm control panel for reliable operation.

Features

• Commercial addressable pull station
• Dual-action push/pull activation
• Rotary decimal addressing
• Dual-color LED status indicator
• Key-reset mechanism
• Polycarbonate housing
• ADA-compliant operating force
• Braille operating instructions
• Plug-in SLC wiring terminals
• Surface or semi-flush mounting

Mounting & Design

The NBG-12LX may be surface mounted using the SB-10 or SB-I/O back box or semi-flush mounted to a standard single-gang, double-gang, or 4-inch square electrical box. An optional BG12TR trim ring is available for selected semi-flush installations.

Its molded polycarbonate housing features a textured finish, highly visible activation handle, and captive screw terminals accepting wire sizes up to 12 AWG.

Protection & Applications

Suitable for:

• Office Buildings
• Schools
• Hospitals
• Hotels
• Retail Facilities
• Warehouses
• Government Buildings
• Industrial Facilities
• Commercial Properties

Compatibility

Compatible with:

• Notifier ONYX Fire Alarm Control Panels
• FlashScan Signaling Line Circuits
• CLIP Signaling Line Circuits
• SB-10 Surface Back Box
• SB-I/O Surface Back Box
• BG12TR Trim Ring
• Standard Single-Gang Electrical Boxes
• Standard Double-Gang Electrical Boxes
• 4-Inch Square Electrical Boxes

Always verify compatibility with the installed fire alarm control panel, protocol, and project requirements before installation. The NBG-12LX is not listed for certain legacy FireWarden or NSP-25 applications; consult the applicable panel documentation when selecting devices.

Technical Specifications

Manufacturer: Notifier

Parent Company: Honeywell

Model: NBG-12LX

Product Type: Addressable Dual-Action Pull Station

Activation Method: Push-In / Pull-Down

Communication Protocol: FlashScan® or CLIP

Operating Voltage: 24 VDC Nominal

Maximum SLC Voltage: 28 VDC

Standby Current: 375 µA Maximum

Alarm Current: 5 mA Maximum

Address Range: 01–159 (FlashScan), 01–99 (CLIP)

Addressing: Rotary Decimal Switches

Status Indicator: Dual-Color LED

Reset Method: Key Reset

Terminal Capacity: Up to 12 AWG

Operating Temperature: 32°F to 120°F (0°C to 49°C)

Operating Humidity: 10%–93% RH Non-Condensing

Construction: Textured Polycarbonate

Mounting: Surface or Semi-Flush

Application: Indoor Commercial Fire Alarm Systems

Listings: UL 38, ULC-S528, ADA compliant operating mechanism, and additional approvals as applicable.

Applications

The Notifier NBG-12LX is designed for commercial fire alarm systems requiring reliable manual alarm initiation with addressable device identification. Typical applications include office buildings, schools, hospitals, hotels, warehouses, industrial facilities, retail centers, government buildings, and other commercial occupancies where compatible Notifier addressable fire alarm systems are installed.
