Description

The Notifier XP10-M ten-input monitor module is an interface between a control panel and normally open contact devices in intelligent alarm systems such as pull stations, security contacts, or flow switches.  Also, the first address on the Notifier XP10-M is set from 01 to 150, and the remaining modules are automatically assigned to the next nine higher addresses. Besides, provisions are included for disabling a maximum of two unused addresses.

The supervised state (normal, open, or short) of the monitored device is sent back to the panel. A common SLC input is used for all modules, and the initiating device loops share a common supervisory supply and ground; otherwise, each monitor operates independently from the others. Furthermore, each XP10-M module has panel-controlled green LED indicators. In addition, the panel can cause the LEDs to blink, latch on, or latch off.

Features / Specifications

• Status indicators
• Rotary Address Switches
• Flexible mounting options
• Ten addressable Class B or five addressable Class A initiating device circuits.
• Temperature range: –10°C to +55°C
• Mounting hardware included.
• Temperature range: 32°F to 120°F (0°C to 49°C) for UL applications; –10°C to +55°C for EN54 applications.
• Humidity: 10% to 85% noncondensing for UL applications; 10% to 93% noncondensing for EN54 applications.
• Dimensions: 6.8″ (172.72 mm) high x 5.8″ (147.32 mm) wide x 1.25″ (31.75 mm) deep.
