Description

Silent Knight SK-CONTROL Supervised Control Module intended for use in intelligent, two-wire systems. Supervises wiring to the connected loads and reports status to the panel as NORMAL, OPEN, as well as SHORT CIRCUIT.

The SK-Control has two pairs of output termination points available for fault-tolerant wiring and a panel-controlled LED indicator

The Silent Knight SK-CONTROL is an addressable notification module for use with Honeywell Silent Knight series fire alarm control panels (FACPs). The SK-CONTROL provides supervised monitoring of wiring to load devices that require an external power supply to operate, such as bells, horns, and strobes. It is also capable of Class B (Styles Y) and Class A (Style Z) supervision.

The SK-CONTROL mounts directly into a 4” square electrical box. Additionally, the box must have a minimum depth of 2-1/8”. Furthermore, a surface mount electrical box (System Sensor® PN SMB500) is available from Silent Knight.

Features / Specifications

• Rotary address switches for fast installation
• Flexible solution for adding notification circuits where needed
• Support for Class B (style Y) or Class A (style Z) wiring
• Panel controlled status LED that flashes green in normal state and is solid red in alarm
• Alarm Current: 7mA per module
