Description

Simplex 4906-9201 Multi-Candela Strobes are individually address and controlled with power, supervision, and control supplied from a TrueAlert Addressable SLC.

Simplex 4906-9201 provides separate audible and visible appliance control functions using a single two-wire circuit that also confirms connection to the individual notification appliance’s electronic circuit. Besides, this operation increases circuit supervision integrity by providing supervision beyond the appliance wiring connections.

Separate controls carried on the same two-wire SLC can significantly reduce installation time and expense for both retrofit and new construction. When Class B (Style 4) wiring is used, wiring can be T- tapped, allowing savings in the distance, wire, junction boxes, and overall installation efficiency.  TrueNAC diagnostics further improve installation efficiency by analyzing individual appliance wiring connections.

Individually addressed and controlled multi-candela V/O (visible only) notification appliances provide:

• Synchronized 1 Hz strobe flash rate
• Wiring supervision to each appliance allowing “T-tapped” connections for Class B circuits to simplify wiring
• Backward compatibility with fixed candela TrueAlert addressable strobes on same Signaling Line Circuit (SLC) allowing convenient expansion as well as replacement
• Compatibility with ADA requirements
• UL listed to Standard 1971
• Appliance LED can be select to display each polling cycle to indicate appliance supervision
• Rear of the housing does not extend into the box and easily mounts to standard electrical boxes
• Access to wall mount in/out wiring terminals (18 AWG to 12 AWG) from front of housing assists
• Mounting options include electrical box adapters, separate covers to convert color, and red wire guards
• Dimensions: 5-1/8” H x 5” W x 2-3/4” D (130 mm x 127 mm x 70 mm)
